Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097

Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097
Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097 Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097 Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097 Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097 Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097

Large Image :  Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097

Product Details:
Place of Origin: China
Brand Name: Eternal Bliss
Certification: ISO9001-2008
Model Number: EB9097
Payment & Shipping Terms:
Minimum Order Quantity: 50kg
Price: USD10/KG ~ USD20/KG
Packaging Details: Pallets
Delivery Time: It depends on the quantity to be ordered.
Payment Terms: by T/T or L/C, Western Union
Supply Ability: 2000 tons per year
Detailed Product Description
Matrerial Grade: H62,H54,H90 Process: Investment Casting,Sand Cast, Gravity Cast
Dimensions: Customer's Drawings Surface Treatment: Shot Blast
Machining: CNC Heat Treatment: T6
Corrosion Type: Anti-corrosive Finishing: Powder Coating
High Light:

aluminum sand casting part

,

cast aluminium alloy

Small ZAlSi7Mg Al Investment Castings High Temperature Up to 1300 Degree EB9097

Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097 0

Casting is an inexpensive and versatile way of forming aluminum into a wide array of products. Due to its low cost, aluminum is the most commonly cast non-ferrous metal in the world. Aluminum is light weight, retains strength, corrosive resistant, high in electrical and thermal conductivity, and is non-magnetic. The geometries achieved through shaping molten aluminum has advantages in manufacturing over fabricating, forging, machining, and welding. Metal casting provides low cost solutions for manufacturers around the world.



Special Features:

1. We can make the Al castings with Investment Cast Process.

2. We can supply finished Al castings with heat-treatment and machining process.

3. The Al castings are for sealing industry.

4. The Al castings are up to 2000kg per piece.

5. Cast aluminum alloy grades and chemical composition are as below:





Standard for Al Alloys

ISO



GB



Chemical Composition (%)(%)
Si Cu Mg Zn Mn Ti Other Al
ZAlSi7Mg ZL101 6.5~7.5   0.25~0.45         Bal.
ZAlSi7MgA ZL101A 6.5~7.5   0.25~0.45     0.08~0.20   Bal.
ZAlSi12 ZL102 10.0~13.0             Bal.
ZAlSi9Mg ZL104 8.0~10.5   0.17~0.35   0.2~0.5     Bal.
ZAlSi5Cu1Mg ZL105 4.5~5.5 1.0~1.5 0.4~0.6         Bal.
ZAlSi5Cu1MgA ZL105A 4.5~5.5 1.0~1.5 0.4~0.55         Bal.
ZAlSi8Cu1Mg ZL106 7.5~8.5 1.0~1.5 0.3~0.5   0.3~0.5 0.10~0.25   Bal.
ZAlSi7Cu4 ZL107 6.5~7.5 3.5~4.5           Bal.
ZAlSi12Cu2Mg1 ZL108 11.0~13.0 1.0~2.0 0.4~1.0   0.3~0.9     Bal.

ZAlSi12Cu1Mg

1Ni1

ZL109 11.0~13.0 0.5~1.5 0.8~1.3       Ni0.8~1.5 Bal.
ZAlSi5Cu6Mg ZL110 4.0~6.0 5.0~8.0 0.2~0.5         Bal.
ZAlSi9Cu2Mg ZL111 8.0~10.0 1.3~1.8 0.4~0.6   0.10~0.35 0.10~0.35   Bal.
ZAlSi7Mg1A ZL114A 6.5~7.5   0.45~0.60     0.10~0.20 Be0.04~0.07 Bal.
ZAlSi5Zn1Mg ZL115 4.8~6.2   0.4~0.65

1.2~

1.8

    Sb0.1~0.25 Bal.
ZAlSi8MgBe ZL116 6.5~8.5   0.35~0.55     0.10~0.30 Be0.15~0.40 Bal.
ZAlCu5Mn ZL201   4.5~5.3     0.6~1.0 0.15~0.35   Bal.
ZAlCu5MnA ZL201A   4.8~5.3     0.6~1.0 0.15~0.35   Bal.
ZAlCu4 ZL203   4.0~5.0           Bal.
ZAlCu5MnCdA ZL204A   4.6~5.3     0.6~0.9 0.15~0.35 Cd0.15~0.25 Bal.
ZAlCu5MnCdVA ZL205A   4.6~5.3     0.3~0.5 0.15~0.35

Cd0.15~0.25

V0.05~0.3

Zr0.05~0.2

B0.005~0.06

Bal.
ZAlRE5Cu3Si2 ZL207 1.6~2.0 3.0~3.4 0.15~0.25   0.9~1.2

Ni0.2~0.3

Zr0.15~0.25

RE4.4~5.0

Bal.
ZAlMg10 ZL301     9.5~11.0         Bal.
ZAlMg5Si1 ZL303 0.8~1.3   4.5~5.5   0.1~0.4     Bal.
ZAlMg8Zn1 ZL305     7.5~9.0

1.0~

1.5

  0.1~0.2 Be0.03~0.1 Bal.
ZAlZn11Si7 ZL401 6.0~8.0   0.1~0.3

9.0~

13.0

      Bal.
ZAlZn6Mg ZL402     0.5~0.65

5.0

~6.5

  0.15~0.25 Cr0.4~0.6 Bal.






Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097 1Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097 1Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097 1Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097 1Production Process

Step 1: Getting orders.



Step 2: Process design by technical department



Step 3: Purchase of raw materials and pattern making &checking



Step 4: Inspection of raw materials



Step 5: Melting by middle-frequency induction furnaces



Step 6: Ladle analysis by Spectrometer



Step 7: De-oxidization, slag-removal, tapping



Step 8: Pouring



Step 9: Openning & fettling



Step 10: Surface & dimensional check



Step 11: Heat treatment



Step 12: Inspection of physical property (UT test,MT test, hardness,impact value µstructure)



Step 13: Packing



Step 14: Shipping





Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097 5

1. 18-year Foundry Operation Experience.

2. Friendly & High Efficient Technical & Commercial Communication.

3. Professional Export Practices: Have Exported to +60 Overseas Countries.





Our Trade Show Small AlSi7Mg Al Investment Castings High Temperature 1300 Degree EB9097 6



Our booth No. 14-A29-5 in Newcast 2015,Germany

Hall 14, Stand No.A29-5.
