| Grade: | Incoloy 800 800H 800HT | Powder Or Not: | Powder Or Not |
|---|---|---|---|
| Dimensions: | Drawing | Application: | Industry, Industry, Heating Elements, Chemical Equipment |
| Packing: | Wooden Case | Quality Control: | 100% Inspected |
| High Light: | nickel based alloys,metal casting |
||
Overview of Incoloy 800 (NO8800) Nickel Based Alloy
| Incoloy800 Typical values (Weight %) | |||||||
| Cr | Ni | C | Si | Mn | P | S | Fe |
| 19.0-23.0 | 30.0-35.0 | ≤0.10 | ≤1.00 | ≤1.50 | ≤0.030 | ≤0.015 | Margin |
| Incoloy800 Mechanical Properties | |||
| Temperature℃ | σЬ/ MPa | σ0.2 / MPa | δ5 /% |
| 100 | 425 | 140 | 160 |
| 300 | 390 | 95 | 115 |
| 500 | 360 | 80 | 110 |
| 600 | 300 | 75 | 95 |
| Incoloy800 Physical Properties | ||||
| Melting Temperature Range | 1350-1400℃ | |||
| Specific Heat | 455J/(kg.℃) | |||
| Thickness | 8.0g/lcm³ | |||
| Magnetism | / | |||
Overview of Incoloy 800H (NO8810) Nickel Based Alloy
| Incoloy 800H Close to the Brand | |||
| GB/T | UNS | Trademark | W.Nr |
| NS112 | N08810 | Incoloy800H | 1.4876 |
| Incoloy800H Typical Values (Weight %) | ||||||||||||
| Alloy | % | Ni | Ge | Fe | C | Mn | Si | Cu | S | Al | Ti | P |
| Incoloy800H | Min | 30 | 19 | Margin | 0.05 | 0.15 | 0.15 | |||||
| Max | 35 | 23 | 0.1 | 1.5 | 1 | 0.75 | 0.015 | 0.6 | 0.6 | 0.03 | ||
| Incoloy800H Physical Properties | ||
| Thickness | 8.0 g/cm3 | |
| Melting Point | 1350-1400 ℃ | |
Overview of Incoloy 800HT (NO8811) Nickel Based Alloy
| Incoloy 800HT Close to the Brand | |||
| UNS | Trademark | W.Nr | |
| NO8811 | Incoloy 800HT | 1.4954 | |
| Incoloy800H Typical Values (Weight %) | |||||||||||
| Alloy | % | Ni | Ge | Fe | C | Mn | Si | Cu | S | Al | Ti |
| Incoloy800HT | Min | 30 | 19 | 0.05 | 0.15 | 0.15 | |||||
| Max | 35 | 23 | Margin | 0.1 | 1.5 | 1 | 0.75 | 0.015 | 0.6 | 0.6 | |
Picture and Video
We specialize in supplying various alloy castings&forgings including ferrous and non-ferrous
castings and forgings with high efficient &friendly service.
| OEM ODM SERVICE |
| TEAM SUPPORT |
| FACTORY SUPPORT |
| SOLD WORLDWIDE |
