ASME SB-751 Inconel 600 Seamless Pipes Welded Tubes

ASME SB-751 Inconel 600 Seamless Pipes Welded Tubes
ASME SB-751 Inconel 600 Seamless Pipes Welded Tubes ASME SB-751 Inconel 600 Seamless Pipes Welded Tubes ASME SB-751 Inconel 600 Seamless Pipes Welded Tubes ASME SB-751 Inconel 600 Seamless Pipes Welded Tubes

Large Image :  ASME SB-751 Inconel 600 Seamless Pipes Welded Tubes

Product Details:
Place of Origin: China
Brand Name: Eternal Bliss
Certification: ISO9001:2008
Model Number: EB6043
Payment & Shipping Terms:
Minimum Order Quantity: 20 Kilogram/Kilograms
Price: $58.00 - $62.00/ Kilogram
Packaging Details: Pallets
Delivery Time: It depends on the quantity to be ordered.
Payment Terms: By T/T or L/C
Supply Ability: 10000 Tons Per Year
Detailed Product Description
Material: Nickel Alloy Grade: Inconel 600
Dimensions: OD 21.3 Mm X 2.77mm X 1000mm/Customized Size Resistance (μΩ.m): Stable
Ultimate Strength (≥ MPa): 730 Elongation (≥ %): 40%
Surface: Smooth Turned/Bright,etc Density: 8.05g/cm3
Process: Forging
High Light:

ASME SB-751 Seamless Pipes

,

ASME SB-751 Welded Tubes

,

Inconel 600 Welded Tubes



Chinese Supplier EB ASME SB-751 Inconel 600 Seamless Pipes and Welded Tubes Price



ASME SB-751 Inconel 600 Seamless Pipes Welded Tubes 0



Properties:


Inconel 600 is a nickel-chromium alloy used for applications that require corrosion and high temperature resistance. This nickel alloy was designed for service temperatures from cryogenic to elevated temperatures in the range of 2000° F. It is non-magnetic,has excellent mechanical properties, and presents the desirable combination of high strength and good weldability under a wide range of temperatures. The high nickel content in Inconel 600 enables it to retain considerable resistance under reducing conditions, makes it resistant to corrosion by a number of organic and inorganic compounds, gives it excellent resistance to chloride-ion stress-corrosion cracking and also provides excellent resistance to alkaline solutions. Typical applications of this nickel alloy include the chemical, pulp and paper, aerospace, nuclear engineering and heat treating industries.


In what form is Inconel 600 Available?
* Sheet
* Plate
* Bar
* Pipe & Tube (welded & seamless)
* Fittings (i.e. flanges, slip-ons, blinds, weld-necks, lapjoints, long welding necks, socket welds, elbows, tees, stub-ends,returns, caps, crosses, reducers, and pipe nipples)
* Wire

What are the characteristics of Inconel 600?
* Resistant to a wide range of corrosive media.
* Virtually immune to chlorine ion stress corrosion cracking
* Non-magnetic
* Excellent mechanical properties
* High strength and good weldability under a wide range of temperatures





In what applications is Inconel 600 used?
* Chemical industry
* Aerospace
* Heat treating industry
* Pulp and paper industry
* Food processing
* Nuclear Engineering
* Gas turbine components

Fabrication with Inconel 600
Alloy 600 can be both hot formed and cold formed using typical processes. Hot working should be performed between 1600° F and 2250° F avoiding any work between1200-1600° F because the ductility decreases in this temperature range. Welding Alloy 600 can be achieved via shielded metal-arc welding, TIG, and MIG.

Material
Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
Shape
Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet
Grade
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L

Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc

Alloy : Alloy 20/28/31

Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g

Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C,
Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602,
Hastelloy C-276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665

Haynes: Haynes 230/556/188

Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20

Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851,
Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 /
UNS N06600 / DIN W. Nr. 2.4816

Incoloy: Incoloy 800/800H/800HT/825/925/926;

GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044

Monel: Monel 400/K500/R405

Nitronic: Nitronic 40/50/60;

Nimonic: Nimonic 75/80A/90/A263 ;


Specification
Wire: 0.01-10mm
Strip: 0.05*5.0-5.0*250mm
Bar: φ4-50mm;Length 2000-5000mm
Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
Standard
GB,AISI,ASTM,DIN,EN,SUS,UNS etc
Inspection
ISO,SGS,BV and so on.

Application
High temperature components such as turbine blades, guide vanes, turbine disks,
high pressure compressor disks,machine manufacturing
and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines


Packaging
1. cases packed in wooden cases
2. paper packaging
3. plastic packing
4. foam packaging
Packaging according to customer requirements or products
Delivery
7-25days orAccording to the product



Chemical Composition:
Composition (%)
C
Cr
Mn
Si
Fe
Cu
S
P
Ni
Inconel 600
≤0.15
14.0-17.0
≤1.00
≤0.50
6.0-10.0
≤0.50
≤0.03
≤0.03
Bal.



ASTM Specifications:
Pipe Smls
Pipe Welded
Tube Smls
Tube Welded
Sheet/Plate
Bar
Forging
Fitting
B167
B517
B163
B516
B168
B166
B564
B366



Product Form
Condition
Tensile (ksi)
.2% Yield (ksi)
Elongation (%)
Hardness
Rod & Bar
Cold-Drawn
80-100
25-50
35-55
65-85
Rod & Bar
Hot-Finished
80-100
30-50
35-55
65-85
Tube & Pipe
Hot-Finished
75-100
25-50
35*55

 -

Tube & Pipe
Cold-Drawn
80-100
25-50
35-55
88 Max
Plate
Hot-Rolled
80-105
30-50
35-55
65-85
Sheet
Cold-Drawn
80-100
30-45
35-55
88 Max





Product Details:



ASME SB-751 Inconel 600 Seamless Pipes Welded Tubes 1ASME SB-751 Inconel 600 Seamless Pipes Welded Tubes 2ASME SB-751 Inconel 600 Seamless Pipes Welded Tubes 3
