ASTM A608 Mo-Re 10 Radiant Tube For Continuous Carburizing Furnaces

China ASTM A608 Mo-Re 10 Radiant Tube For Continuous Carburizing Furnaces supplier
ASTM A608 Mo-Re 10 Radiant Tube For Continuous Carburizing Furnaces supplier ASTM A608 Mo-Re 10 Radiant Tube For Continuous Carburizing Furnaces supplier ASTM A608 Mo-Re 10 Radiant Tube For Continuous Carburizing Furnaces supplier ASTM A608 Mo-Re 10 Radiant Tube For Continuous Carburizing Furnaces supplier ASTM A608 Mo-Re 10 Radiant Tube For Continuous Carburizing Furnaces supplier

Large Image :  ASTM A608 Mo-Re 10 Radiant Tube For Continuous Carburizing Furnaces

Product Details:

Place of Origin: China
Brand Name: Eternal Bliss
Certification: ISO9001-2008
Model Number: EB13246

Payment & Shipping Terms:

Minimum Order Quantity: 200kg
Price: USD2 ~ USD10/kg
Packaging Details: by Plywood Cases
Delivery Time: It depends on the quantity to be ordered.
Payment Terms: by T/T or L/C, Western Union
Supply Ability: 100,000.00
Contact Now
Detailed Product Description
Material Grade: ASTM A608 Mo-Re 10 Cast Process: Centrifugal Cast And Investment Cast
Working Temperature: Up To 1300℃ Surface Finish: As Cast Condition
Application: Carburizing Furnace Certification: ISO 9001

ASTM A608 Mo-Re 10 Radiant Tubing for Continuous Carburizing Furnaces EB13246



Big High Alloy Furnace Rollers EB13082



ASTM A608 Mo-Re 10 Radiant Tubing

The Radiant Tubes are made from ASTM A608 Mo-Re 10.



Special Characteristics:



1. Chemlcal Analysis of each heat of Radiant Tubes is done with our Spetromete.

2. The tube matrix will be checked with our mlcroscope;

3. We can do fully machining on the Radiant Tubes.

4. Production Process: centrifugal cast process + Investment process.

5. We can make the cast tubes as per customer drawings.

6. Diameter: 50mm - 500mm; Length: less than 3500mm.

7. Material grades:


ASTM Alloy C Cr Ni Other Description
30/50 W 22H® 0.45 30 50 W 4 The alloy is wholly austenitic and is intended for use at elevated temperatures up to 2200° F (1204° C).
HP+W MO-RE®1 0.45 25 35 W 1.5 Tungsten addition increases creep strength. Useful to 2000°/2100° F (1093°/1149°C). MO-RE® 1 is a good option for use in severe high temperature furnace roll and radiant tube applications.
28/48 W+Co Super 22H® 0.45 28 48 W 5 Co 3 Alloy of choice for extreme high temperature service to 2200° F (1066° to 1200° C).
  MO-RE®2 0.2 33 50 W 17+Al Exceptional strength and oxidation resistance to 2400° F (1315° C).
HP Nb LC MO-RE®9 0.09 25 35 Nb 1 MO-RE ® 9 is used primarily for parts located outside of furnace such as transfer lines and headers. It is designed for applications which require high ductility after aging.
A608 MO-RE ®10 0.4 25 35 Nb 1.2 MO-RE ®10 is a fully austenitic alloy with controlled additions of columbium (niobium) for ethylene pyrolysis tubing. It has improved high temperature strength and resistance to carburization and oxidation up to 2000° F (1093° C).
HP+Nb+MA MO-RE ®10 MA 0.45 25 35 Nb 1.2 Ti Rare Earths MO-RE ®10 MA is microalloyed with additions of columbium (niobium), zirconium and titanium for improved high temperature strength and resistance to carburization and oxidation up to 1975 °F (1079 °C). Microalloying produces fine, stable carbides which retard dislocation movement, thereby increasing elevated temperature strength and creep resistance. Intended for ethylene pyrolysis applications.
A297 A351 MO-RE ®21 0.1 20 32 Nb 1.2 Low carbon, columbium strengthened alloy with excellent thermal fatigue / thermal shock resistance. MO-RE 21 is a cast alternative to wrought alloy 800HT.
  MO-RE ®35 MA 0.45 28 36 Al, Rare Earths MO-RE ® 35 MA is a fully austenitic heat resistant alloy developed by Duraloy primarily for plate heat treating furnace roll applications. MO-RE ®35 MA is microalloyed with additions of aluminum, titanium and proprietary rare earth additions for improved creep strength at furnace operating temperatures. Microalloying produces fine, stable carbides which retard dislocation movement, thereby increasing elevated temperature strength and creep resistance. Primarily intended for use in plate furnace rolls.
35/45 Nb+MA MO-RE®
40 MA
0.45 34 45 Nb 1 Ti Rare Earths MO-RE ®40MA has exceptional resistance to carburization and oxidation up to 2100 °F (1149 °C).
  MO-RE ®49 0.4 23 5   MO-RE ®49 is an iron-chromium-nickel heat resistant alloy developed for aerospace tooling.
  MO-RE® 2150         These Cr-Ni-W alloys are produced to unique chemistries for each customer to work in their dry tunnel furnace roll application.
A1002 Nickel Aluminide         R&D 100 Award Winner Nickel-Aluminum alloy, developed and patented by Oak Ridge National Laboratory and licensed to Duraloy. Alloy shows exceptional resistance to creep at elevated temperatures. Also shows strong resistance to carburization in service. Excellent selection for plate hardening furnace rolls.
  SUPERTHERM® 0.45 25 35 Co 15 W 5 Supertherm exhibits excellent oxidation resistance & high temperature strength to 2300° F (1260 °C). Supertherm is an excellent alloy for use in high temperature press platens or other applications where high temperature strength is critical.
  TMA®4505 0.3 20 25 W, Nb additons TMA ®4505 is a heat resistant alloy developed by Duraloy for SuperPlastic and Hot Press tooling applications. It is a modification of ASTM A297 Grade HN with improved properties.
HK-40+MA TMA®4700 0.4 25 20 W, Nb & Ti additions TMA®4700 is an iron-chromium-nickel (modified HK type) heat resistant alloy. TMA ®4700 is microalloyed with additions of columbium (niobium), tungsten, titanium and rare earths for superior stress rupture properties to 2000°F (1093°C). Microalloying produces fine, stable carbides which retard dislocation movement, thereby increasing elevated temperature strength and creep resistance.
  TMA®4701         R&D 100 Award Winner heat resistant alloy developed by Duraloy. TMA®-nickel (modified HK type). TMA® 4701 has a proprietary, microalloyed, computer designed chemistry which gives the alloy better high temperature creep properties than similar alloys. It is intended primarily for reforming applications.
HP+Nb+MA (LoSil) TMA®6300 0.4 25 35 Nb 1.2 Ti Rare Earths TMA® 6300 is a fully austenitic heat resistant alloy. TMA®6300 is microalloyed with additions of columbium (niobium), titanium and rare earths for improved high temperature strength and resistance to carburization and oxidation up to 1950 ° F (1066 ° C). Microalloying produces fine, stable carbides which retard dislocation movement, thereby increasing elevated temperature strength and creep resistance. Intended primarily for reforming applications.
HP+Nb+MA (LoSil) TMA® 6301   25 35 Nb 1.2 Ti Rare Earths R&D 100 Award Winner heat resistant alloy developed by Duraloy. TMA ®6301has a proprietary, microalloyed, computer designed chemistry which gives the alloy better high temperature creep properties than similar alloys. It is intended primarily for reforming applications.









Production Flow Chart

Step 1: Getting orders.



Step 2: Process design by technical department



Step 3: Purchase of raw materials and pattern making &checking



Step 4: Inspection of raw materials



Step 5: Melting by middle-frequency induction furnaces



Step 6: Ladle analysis by Spectrometer



Step 7: De-oxidization, slag-removal, tapping



Step 8: Pouring



Step 9: Openning & fettling



Step 10: Surface & dimensional check



Step 11: Heat treatment



Step 12: Inspection of physical property (UT test,MT test, hardness,impact value, matrix structure)



Step 13: Packing



Step 14: Shipping





Big High Alloy Furnace Rollers EB13082

1. 18-year Foundry Operation Experience.

2. Friendly & High Efficient Technical & Commercial Communication.

3. Professional Export Practices: Have Exported to +60 Overseas Countries.



Our Trade Show Big High Alloy Furnace Rollers EB13082



Our booth No. 14-A29-5 in Newcast 2015,Germany

Hall 14, Stand No.A29-5.



Contact Us for further information about products & service:

Mr.John Liu

Project Manager

Tel: 0086-188 0059 6372

Fax: 0086-510-6879 2172

ASTM A608 Mo-Re 10 Radiant Tube For Continuous Carburizing FurnacesASTM A608 Mo-Re 10 Radiant Tube For Continuous Carburizing FurnacesEmail : cast@ebcastings.com;ebcastings@163.com



Skype ID:julia.zhu26

QQ: 217 039 6403

What's app: 0086-130 930 23772

www.ebcastings.com

Eternal Bliss Alloy Casting & Forging Co.,LTD.

Add.: J-Sci-Tech Park, Binhu District,Wuxi,214122, Jiangsu,China
