|Impact Value:||≥60J||Heat-treatment::||Normalizing + Tempering|
|Material Grade:||AS2074 L2B||Surface Treatment:||Shot Blasting|
|Production Process:||Sand Cast||Microstructure:||Pearlitical|
|Mill Liner Type:||Sag Mill Liners|
ball mill liner replacement,
discharge grate liners
Our wear parts are designed based on your process, application, drilling pattern and liner history using 2D/3D DEM simulations. Working with the front-runner, you can be sure to have access to the latest technology on the market.
We carry out constant improvements to make sure that your mill lining and grinding media are always ideal for your current operating conditions.
Material Grade:Cr-Mo Alloy Steel;
Quality Level: As per National Standard & International Standards.
Production Process: Sand Process
1.The material of SAG mill liners are low C or high C Cr-Mo Alloy steel,which depends on the specific working condition of the SAG mill.
2.The hardness of AS2074 L2B is HB310-HB380.
3. We can make big size SAG mill liner castings with Sodium Silicate Sand Process & Resin Sand Process.
4. We can supply alloy steel SAG mill liner castings with proper heat-treatment process.
5. We can produce Cr-Mo alloy steel SAG Mill castings as per AS2074 L2B, L2C, GB/T 26651-2011.
6. Metallographic structure of AS2074 L2B Steel is Pearlitic.
7. Chemical Composition
|AS 2074 L2C||0.70-0.90||<0.75||0.50-1.20||<0.06||<0.06||1.30-2.40||0.20-0.40|
Step 1: Getting orders.
Step 2: Process design by technical department
Step 3: Purchase of raw materials and pattern making &checking
Step 4: Inspection of raw materials
Step 5: Melting by middle-frequency induction furnaces
Step 6: Ladle analysis by Spectrometer
Step 7: De-oxidization, slag-removal, tapping
Step 8: Pouring
Step 9: Openning & fettling
Step 10: Surface & dimensional check
Step 11: Heat treatment
Step 12: Inspection of physical property (UT test,MT test, hardness,impact value µstructure)
Step 13: Packing
Step 14: Shipping
