| Name: | Manhole Cover EN124 D400 | Material: | Ductile Iron Or Gray Iron |
|---|---|---|---|
| Class: | A15-C250 | Size: | Customized Size |
| Standard: | EN124-2015 EN1433 | Surface Treatment: | Zinc Plated, Anodizing,Painting,Polishing |
| Paint Color: | As Customer's Request | Finish: | Coating Will Be Black Bituminous Paint, Or As Customer Requirements |
| Application: | Pedestrian, General Commercial Or Driveway Situations | ||
| High Light: | cast iron tube,ductile iron casting parts |
||
EN124 D400 C250 Heavy Duty Ductile Iron Manhole Cover 800x800 Foundry
Introduction:
Manhole Cover is removable plate forming the lid over the opening of a manhole,to prevent anyone or anything from falling in, and to keep out unauthorized persons and material.We produce various classes of manhole cover and gratings in gray iron or ductile iron from Class A15 to F900 according to customer's sample or requirment.
Material | Ductile iron |
Surface Treatment | Painting |
Load | A15 B125 C250 D400 E600 F900 |
Standard | EN124-2015 EN1433 |
Feature | Easy to install noise reduction |
Eternal Size | Cover Diameter | Clear Opening | Depth | Weight | Loading Capacity |
φ600mm | φ512mm | φ485mm | 53mm | 55kg | EN124 D400 |
φ850mm | φ725mm | φ700mm | 100mm | 72kg | EN124 D400 |
φ850mm | φ680mm | φ650mm | 75mm | 54kg | EN124 C250 |
φ950mm | φ850mm | 800mm | 100mm | 95kg | EN124 D400 |
φ1150mm | φ1050mm | φ1000mm | 100mm | 210kg | EN124 D400 |
