| Material Grade: | ASTM A494 CZ100 | Cast Process: | Investment Process |
|---|---|---|---|
| Surface Finish: | Ra 6.3 | Surface Treatment: | Shot Blast |
| Size Tolerance: | CT8 | Certificate: | ISO9001 |
| High Light: | nickel based alloys,metal casting |
||
Corrosion Resistance. Nickel-base alloys offer excellent corrosion resistance to a wide range of corrosive media. However, as with all types of corrosion, many factors influence the rate of attack. The corrosive media itself is the most important factor governing corrosion of a particular metal.
Quality Level: As per National Standard & International Standards.
Sizes available: As per drawings.
Application Field: Valve Seat, bearing sleeve,pump shaft,seeling ring,wear gaskt,bearing bush,hot extruding dies,steam turbine blade,food processing industry,valve gate,valve board,valve seat ring,dental industry.
Material Grade:
| Metal No: | Chemical Compostion(W%) | |||||||||
| C | Si | Cr | Mo | Mn | Fe | Cu | Ti | Ai | Ni | |
| Ni200Z | 1.00 | 2.00 | -- | -- | 1.50 | 3.00 | 1.25 | -- | -- | Bal |
| Ni202Z | 0.15 | 3.30 | -- | -- | -- | -- | -- | B2.3 | -- | Bal |
| Ni205Z | 0.12 | 1.00 | 16.50 | 17.00 | 1.00 | 6.50 | -- | W:4.50 | V:0.30 | Bal |
| Ni206Z | 0.12 | 1.00 | 1.00 | 28.00 | 1.00 | 5.00 | -- | -- | V:0.40 | Bal |
| Ni207Z-NZ | -- | 1.20 | 25.00 | 11.00 | -- | -- | -- | -- | -- | Bal |
| Ni219Z | -- | -- | 12.70 | 9.00 | -- | -- | Be 2.0 |
0.4 | 2 | Bal |
| Ni222Z | -- | 0.50 | 22.00 | 13.00 | 0.70 | 4.00 | -- | -- | Bal | |
| Ni230 | 0.30 | 1.50 | -- | -- | 1.50 | 3.50 | 30.00 | Nb:2.00 | -- | Bal |
| Ni235 | 0.35 | 2.00 | -- | -- | 1.50 | 3.50 | 30.00 | Nb:0.50 | -- | Bal |
| Ni240Z | 0.35 | 1.25 | -- | -- | 1.50 | 3.50 | 29.50 | Nb:0.50 | -- | Bal |
| Ni250Z | 0.12 | 0.30 | -- | -- | 1.50 | 2.00 | 27-33 | 0.60 | 3.00 | 68.00 |
| Ni255 | 0.05 | 0.50 | 12.50 | 3.00 | 1.50 | 1.70 | bi:4.00 | sn:4.00 | -- | Bal |
| Ni260Z | 0.40 | 3.00 | 15.5 | -- | 1.50 | 11.00 | -- | -- | -- | Bal |
| Ni262Z | 0.06 | 1.00 | 21.5 | 9.5 | 1.00 | 5.00 | -- | Nb:4.00 | -- | Bal |
| Ni264 | 0.03 | -- | 60.00 | -- | -- | 0.40 | -- | -- | -- | Bal |
| Ni274Z | 0.02 | 0.80 | 16.00 | 16.5 | 1.00 | 2.00 | -- | W:1.00 | -- | Bal |
| Ni278Z | 0.08 | 0.35 | 19.00 | 3.00 | 0.35 | Bal | 0.30 Co:1.00 |
0.90 Nb:5.00 |
0.60 | 53.00 |
Production Process
Step 1: Getting orders.
Step 2: Process design by technical department
Step 3: Purchase of raw materials and pattern making &checking
Step 4: Inspection of raw materials
Step 5: Melting by middle-frequency induction furnaces
Step 6: Ladle analysis by Spectrometer
Step 7: De-oxidization, slag-removal, tapping
Step 8: Pouring
Step 9: Openning & fettling
Step 10: Surface & dimensional check
Step 11: Heat treatment
Step 12: Inspection of physical property (UT test,MT test, hardness,impact value µstructure)
Step 13: Packing
Step 14: Shipping
