Product Details:
Payment & Shipping Terms:
|
| Material Grade: | ASTM A494 M25S | Certificate: | ISO9001 |
|---|---|---|---|
| Corrosion Resistance: | High | Surface Treatment: | Shot Blast |
| Cast Process: | Silica Sol Investment Cast Process | Application: | Valve Seat, Bearing Sleeve,pump Shaft |
| High Light: | nickel based alloys,metal casting |
||
Because of the sticky and high surface extension force of metal drops of Nickel Base Alloy melting metal is inferior to carbon steel’s metal drops which have higher wetting effect; welder might have false impression that by raising welding current the metal pool’s wetting effect will be enhanced. Actually, using strong welding current will not improve the wetting effect, but instead will create more defects because the high heat will cause the melting pool’s deoxidizer to evaporate ; which will allow welding groove to form blow holes more easily.
Items suitably crated to avoid damage during transit & storage one item per crate.
Quality Level: As per National Standard & International Standards.
Sizes available: Dia.50mm--1500mm.
Application Field: Mining Industry, Valve and Pump Industry,Heat-treatment Industry, Metallurgical Industry, Cement Industry,Power plants, Oil, Gas Industry.
Material Grade:
| Metal No: | Chemical Compostion(W%) | |||||||||
| C | Si | Cr | Mo | Mn | Fe | Cu | Ti | Ai | Ni | |
| Ni200Z | 1.00 | 2.00 | -- | -- | 1.50 | 3.00 | 1.25 | -- | -- | Bal |
| Ni202Z | 0.15 | 3.30 | -- | -- | -- | -- | -- | B2.3 | -- | Bal |
| Ni205Z | 0.12 | 1.00 | 16.50 | 17.00 | 1.00 | 6.50 | -- | W:4.50 | V:0.30 | Bal |
| Ni206Z | 0.12 | 1.00 | 1.00 | 28.00 | 1.00 | 5.00 | -- | -- | V:0.40 | Bal |
| Ni207Z-NZ | -- | 1.20 | 25.00 | 11.00 | -- | -- | -- | -- | -- | Bal |
| Ni219Z | -- | -- | 12.70 | 9.00 | -- | -- | Be 2.0 |
0.4 | 2 | Bal |
| Ni222Z | -- | 0.50 | 22.00 | 13.00 | 0.70 | 4.00 | -- | -- | Bal | |
| Ni230 | 0.30 | 1.50 | -- | -- | 1.50 | 3.50 | 30.00 | Nb:2.00 | -- | Bal |
| Ni235 | 0.35 | 2.00 | -- | -- | 1.50 | 3.50 | 30.00 | Nb:0.50 | -- | Bal |
| Ni240Z | 0.35 | 1.25 | -- | -- | 1.50 | 3.50 | 29.50 | Nb:0.50 | -- | Bal |
| Ni250Z | 0.12 | 0.30 | -- | -- | 1.50 | 2.00 | 27-33 | 0.60 | 3.00 | 68.00 |
| Ni255 | 0.05 | 0.50 | 12.50 | 3.00 | 1.50 | 1.70 | bi:4.00 | sn:4.00 | -- | Bal |
| Ni260Z | 0.40 | 3.00 | 15.5 | -- | 1.50 | 11.00 | -- | -- | -- | Bal |
| Ni262Z | 0.06 | 1.00 | 21.5 | 9.5 | 1.00 | 5.00 | -- | Nb:4.00 | -- | Bal |
| Ni264 | 0.03 | -- | 60.00 | -- | -- | 0.40 | -- | -- | -- | Bal |
| Ni274Z | 0.02 | 0.80 | 16.00 | 16.5 | 1.00 | 2.00 | -- | W:1.00 | -- | Bal |
| Ni278Z | 0.08 | 0.35 | 19.00 | 3.00 | 0.35 | Bal | 0.30 Co:1.00 |
0.90 Nb:5.00 |
0.60 | 53.00 |
Production Process
Step 1: Getting orders.
Step 2: Process design by technical department
Step 3: Purchase of raw materials and pattern making &checking
Step 4: Inspection of raw materials
Step 5: Melting by middle-frequency induction furnaces
Step 6: Ladle analysis by Spectrometer
Step 7: De-oxidization, slag-removal, tapping
Step 8: Pouring
Step 9: Openning & fettling
Step 10: Surface & dimensional check
Step 11: Heat treatment
Step 12: Inspection of physical property (UT test,MT test, hardness,impact value µstructure)
Step 13: Packing
Step 14: Shipping
1. 18-year Foundry Operation Experience.
2. Friendly & High Efficient Technical & Commercial Communication.
3. Professional Export Practices: Have Exported to +60 Overseas Countries.
